Digital Headend   > Professional IRD

Features


  • Supports DVB-S/S2 (or DVB-C/DVB-T/DTMB) RF receiving & demodulation, TS descrambling
  • Supporting up to four CAMs and can be operating at independent and (or) cascading mode
  • Up to 72Mbps of descrambling bit rate each CAM, meet different bandwidth requirements from SD to HD
  • Supports a 280Mbps of maximum de-scrambling output bit rate and 32 TV programs simultaneously
  • Real-time bit rate statistics and program information analysis
  • Standard common interface complied with EN 50221, supporting most of the major CA systems
  • Supports scrambled programs which complied with BISS mode 1 and mode E
  • Supports TS-over-UDP output via Gigabit Ethernet and ASI outputs
  • Supports Web and SNMP management and maintenance
  • SPTS and MPTS are available
  • Front panel control and LCD display
  • Specification
